TV Stick R5   Products

SoC: Allwinner IK318
DRAM: 64bit LPDDR4 1GB (2GB Optional)
"Flash: EMMC 8GB
(16GB Optional)"
OS: Android 10.0
SV6256P Wi-Fi 2.4G+5GHz 802.11 a/b/g/n
Product profile Product parameters


Basic parameters
SystemSoC:Allwinner IK318
CPU: Quad core ARM Cortex-A53
GPU: Mali-G31,OpenGL3.2,Vulkan1.1,OpenCL2.0
EMCP: DDR3 1GB (2GB 4GB Optional)
OS:   Android 12.0
NetworkRJ45:NC
Wi-Fi:Wi-Fi 2.4G+5GHz
BT: BT5.X
I/O
Video/Audio InputHDMI 2.0a
Peripheral InterfaceUSB2.0 HOSTx1, TFx1,Micro USBx1,
Power InterfaceTYPE-C 5V@2A,
Other InterfaceMini USB to IR receiver, LED indicator
Media
VideoVideo decoder:
H.265 MP@L6.1 10-bit decoder up to 8K@22fps;
VP9 Profile 2 decoder up to 4K@30fps;
AVS2 JiZhun 10-bit decoder up to 4K@60fps;
H.264 BP/MP/HP@L4.2 decoder up to 4K@30fps;
Multi-format 1080p@60fps video playback formats,including H.264 BP/MP/HP, H.263 BP, VP8, MPEG-1 MP/HL,MPEG-2 MP/HL, MPEG-4 SP/ASP@L5, AVS+/AVS JiZhun,WMV9/VC1, etc
Format:
MPEG 1/2/2.5, Audio Layer 1/2/3, WMA Version 4/4.1/7/8/9, WMA Pro, LPCM, PCM, Vorbis, Flac, ALAC, APE, AAC-LC/HEAAC/HE-AAC v2, Real Audio(AC-3 Optional )
AudioFormat:
MP3, WMA, WAV, OGG, M4A, MP4, AAC, APE, FLAC, ALAC, MPEG, MP1, MP2, MPA etc.
Subtitle FormatSMI, SRT, SSA, ASS,SUB, SUB+IDX, ISO Navigation
Photo FormatHD JPEG/BMP/GIF/PNG/TIFF
Features
Network StreamingHTML5, RTSP, HLS, Smooth streaming
Multi-screen interactiveMiracast, DLNA and Airplay
System UpgradingUpgrading via USB disk or internet
Local Media PlaybackVideo/Audio/Picture
External StorageUSB storage max to 32GB (FAT16/FAT32/NTFS)
GamesAndroid 2D/3D games
APPKODI(XBMC),Facebook, YouTube, Skype, Google play etc.
Other parameters
Power Consumption
Operation Temperature0~40℃, Humidity<95%
Physical characteristicsItem size:
Packing size:
Weight:
Pcs/Carton :
N.W:         G.W:
Material: plastic
Proposed AccessoryPower Adapter, HDMI cable, Optional:Remote control and Battery, User manuale
