Allwinner IK318 Quad-Core64-bitARM Cortex-A53
RAM：2GB DDR3 4GB DDR3（Optional）
Memory Size：16GB EMMC 32GB (Optional)
Build in Wi-Fi 2.4GHz+5GHz+BT5.2
Android 12.0
Product center
Product center
INNOVATION/QUALITY/COST/SERVICE
Product profile
Product parameters
| Basic parameters | ||
| System | SoC: Allwinner IK318 | |
| CPU: Quad core ARM Cortex™-A53 | ||
| GPU: Mali-G31,OpenGL3.2,Vulkan1.1,OpenCL2.0 | ||
| RAM: 2G/4G | ||
| ROM: 16G/32G/64G | ||
| OS: Android 12.0 | ||
| Network | RJ45：Interface 10M/100M adaptive | |
| Wifi：Build in Wi-Fi 2.4GHz+5GHz+BT5.2 | ||
| I/O | ||
| Video Output | HDMI2.0a(4K60), AV | |
| Network | RJ45, Buildin Wi-Fi antenna | |
| Peripheral Interface | USB2.0x2 | |
| Other Interface | IR receiver, LED indicator | |
| Media | ||
| Video | Decoder: H.265 MP@L6.1 10-bit decoder up to 8K@22fps; VP9 Profile 2 decoder up to 4K@30fps; AVS2 JiZhun 10-bit decoder up to 4K@60fps; H.264 BP/MP/HP@L4.2 decoder up to 4K@30fps; Multi-format 1080p@60fps video playback formats,including H.264 BP/MP/HP, H.263 BP, VP8, MPEG-1 MP/HL,MPEG-2 MP/HL, MPEG-4 SP/ASP@L5, AVS+/AVS JiZhun,WMV9/VC1, etc | |
| Format: MKV, TS, M2TS, MOV, MP4, RM, RMVB, AVI, MPG, MPEG, DAT, VOB, FLV etc. | ||
| Audio | Decoder: MPEG 1/2/2.5, Audio Layer 1/2/3, WMA Version 4/4.1/7/8/9, WMA Pro, LPCM, PCM, Vorbis, Flac, ALAC, APE, AAC-LC/HEAAC/HE-AAC v2, Real Audio, AC-3/DD+/AC-4, MPEG-H | |
| Format: MP3, WMA, WAV, OGG, M4A, MP4, AAC, APE, FLAC, ALAC, MPEG, MP1, MP2, MPA etc. | ||
| Subtitle Format | SMI, SRT, SSA, ASS,SUB, SUB+IDX, ISO Navigation | |
| Photo Format | HD JPEG/BMP/GIF/PNG/TIFF | |
| Features | ||
| Network Streaming | HTML5, RTSP, HLS, Smooth streaming | |
| Multi-screen interactive | Miracast, DLNA and Airplay | |
| Local Media Playback | Video/Audio/Picture | |
| External Storage | USB storage max to 2TB (FAT32/NTFS) | |
| System Upgrading | Upgrading via USB disk or internet | |
| Other parameters | ||
| Input Voltage | DC IN 5V/2A | |
| Power Consumption | 8W Max | |
| Operation Temperature | 0~40℃, Humidity<95% | |
| Physical characteristics | 40/PCS 57.5*38*23.8cm N.W:11KG G.W:12kG | |
| Proposed Accessory | Power adapter, User manual, HDMI cable, BT Voice RCU | |
